Product Details:
|
| Product Name: | Galvanized Steel Coil | Zinc Coating: | 30-200g |
|---|---|---|---|
| Spangle: | Mini, Normal, Reuglar Spangle, Minimized, Zero | Material: | ASTM/AISI/SGCC/CGCC/TDC51DZM/TDC52DTS350GD/TS550GD/DX51D+Z Q195-q345 |
| Thickness: | 0.12MM-1.2MM | Width: | 1250mm Or Under |
| High Light: | Wu Steel Galvanized Steel Coil,Galvanized Steel Coil 0.3mm,0.5mm gi sheet coil |
||
Wu Steel Galvanized Steel Coil 0.3mm 0.4mm 0.5mm DC51D+Z 3-8Tons
Description:
Hot-rolled products have excellent properties such as high strength, good toughness, easy processing and good weldability, so they are widely used in manufacturing industries such as steel, construction, machinery, boilers, and pressure vessels.
Application range:
(1) After annealing, it is processed into ordinary cold rolling.
(2) The galvanizing unit with pre-annealing treatment device processes galvanizing.
(3) Panels that basically do not need to be processed.
| Product name | Galvanized steel sheet |
| Thickness | 0.12mm-1.2mm |
| Width | 1000mm,1220mm,1219mm,1250mm,1500mm,1800mm,2000mm |
| Zinc coating | 40g,60g, 80g, 90,100g, 120g, 140g,180g, 200g, 250g, 275g and so on. |
| Standard | ASTM, AISI, DIN, EN, JIS |
| Material | SGCC,DC51D,DX51D,DX52D,SGCD,Q195,Q235,SGHC,DX54D, S350GD, S450GD, |
| Spangle | Zero spangle,Mini spangled,Regular spangle or Big spangled |
| Surface treatment | Chromated and oiled, chromated and non-oiled |
| Packing | Export standard. |
| Payment | T/T, L/C or DP |
| Quality | Soft or hard quality |
|
STEEL GRADE |
CHEMICAL COMPOSITION % | MECHANIC PROPERTY | C.B OF COATING | ||||||
| C | Si | Mn | S | p | T.S | Y.S | E.L | ||
| x103 | x103 | x102 | x103 | x103 | Mpa | Mpa | % | d=180 | |
|
JIS G3302 SGCC |
12 | 30 | 41 | 31 | 21 | 480 | 300 | 13 | OK |
|
JIS G3302 SGCH |
12 | 10 | 21 | 18 | 6 | 680 | 650 | 20 | OK |
|
ASTM 653 CS.B |
29 | 30 | 60 | 35 | 30 | 386 | 250-380 | 20 | OK |
| DX51D+Z | 20 | 21 | 18 | 1.8 | 11 | 355 | 245 | 38 | OK |
| G550 | 12 | 6 | 73 | 5 | 17 | 715 | 654 | 8 | OK |
Product Details:
Surface Details:
1. Regular spangled 2. Mini spangled
3. Big spangled 4. Zero spangled
Packing and Shipping:
Certification:
FAQ:
1.How many tons one 20 GP or 40 GP could load?
One 20 GP could load about 20 tons. And 40 GP load about 24 tons. It depends on the different specification.
2.What market do you mainly sell to?
Our products have exported to Singapore, Indonesia, South Korea, Dubai, Pakistan, Sri Lanka, Vietnam, Iran, Malaysia, Mexico, Chile, Brazil, Holland, Italy, Belgium, , Moldova, Paraguay, Uruguay, Germany, Spain, USA etc.
3.What's your payment term?
Usually we do TT and LC or combined.
4.What's your trade term?
Usually we do CIF,FOB,CFR,EXW.
