Hot Dip Galvanized Steel Sheet Gi Sheet Metal SGCC Zinc40-275 Coated Steel

I'm Online Chat Now

Hot Dip Galvanized Steel Sheet Gi Sheet Metal SGCC Zinc40-275 Coated Steel

Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel
Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel

Large Image :  Hot Dip Galvanized Steel Sheet Gi Sheet Metal SGCC Zinc40-275 Coated Steel

Product Details:
Place of Origin: Jiangsu, China
Brand Name: LIAN ZHONG
Certification: ISO9001 14001 BV TUV PED DNV etc
Model Number: SGCC DX51D etc.
Payment & Shipping Terms:
Minimum Order Quantity: 1 MT
Price: Negotiable
Packaging Details: Exporting package/wooden box package/Or per customers' requirements
Delivery Time: 3~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 Ton/Tons per Month

Hot Dip Galvanized Steel Sheet Gi Sheet Metal SGCC Zinc40-275 Coated Steel

Description
Product Name: Galvanized Sheet Zinc Steel Sheet Dx51D/Dc51D/SGCC/SPGC Z40-275 Surface Treatment: Regular Spangle, Minimal Spangle,Zero Spangle
Type: Steel Plate Length: 6 M
Thickness: 0.12-4.0 Mm / BWG / AWG Or As Your Request Application: Making Pipes, Cutting Sheets, Making Small Tools
Technique: Cold Rolled Based, Cold Rolled Grade: SGCC DX51D
Standard: ASTM/AISI/JIS Hardness: Soft
Highlight:

Hot Dip Galvanized Plain Sheet

,

Galvanized Plain Sheet SGCC

,

gi sheet metal Coated Steel

Factory Supplier Zinc40-275 Coated Steel Hot Dip Galvanized Steel Sheet Plate Sgcc

Product Description:



Product name
Zinc40-275 Coated Steel Hot Dip Galvanized Steel Sheet Plate Sgcc
Standard
ASTM,DIN,JIS,BS,GB/T,GB,EN
Material
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490, SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ
CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Application
galvanized steel coil is one of the most widely used products, used extensively in the building sector, automotive, agricultural and other areas where the steel needs to be protected from corrosion.
Thick
0.12-4.0 mm / BWG / AWG or as your request
Width
20-1500 mm or as your request, Normal width is 914/1000/1219/1250/1500 mm
Zinc Coating
30~600 G/M2
Surface Structure
Regular spangle,Minimum spangle, Zero spangle, Big spangle
Surface Treatment
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U) , Chromated/Non-Chromated, Oiled/Non-oiled, Skin pass
Package
Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by seven steel belt.or according to customer's requirement
Description
Galvanized steel coil is mild steel with a coating of zinc. The zinc protects the steel by providing cathodic protection to the exposed steel, so should the surface be damaged the zinc will corrode in preference to the steel.



Chemical Composition
GRADE C Si Mn P S Ti
SGCC/DX51D+Z ≤0.10 ≤0.50 ≤0.60 ≤0.10 ≤0.030 ≤0.020
DX52D+Z ≤0.10 ≤0.50 ≤0.60 ≤0.10 ≤0.030 ≤0.020
SGCD/DX53D+Z ≤0.10 ≤0.30 ≤0.50 ≤0.05 ≤0.030 ≤0.020
SGCE/DX54D+Z ≤0.10 ≤0.30 ≤0.30 ≤0.03 ≤0.020 ≤0.020
DX56D+Z ≤0.10 ≤0.30 ≤0.30 ≤0.03 ≤0.020 ≤0.020
Structural ≤0.20 ≤0.60 ≤1.70 ≤0.10 ≤0.045



Product Details

galvanized steel coil is one of the most widely used products, used extensively in the building sector, automotive, agricultural and other areas where the steel needs to be protected from corrosion.



Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel 0Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel 1





































Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel 2Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel 3















































Applications



Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel 4

Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel 5



Packing



Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel 6



Shipping



Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel 7



Our certifications



Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel 8



Factory Environment



Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel 9

Hot Dip Galvanized Steel Sheet Gi Sheet Metal  SGCC Zinc40-275 Coated Steel 10



FAQ



Q1: Are you trading company or manufacturer ?
A: We are a professional manufacturer with 50 years' experience and have took part in trading for 20 years.


Q2: How about your quality and how do you guarantee the quality?
A: All products we supply is primary as you need, Our company is certificated to ISO9001:2008, and every product will be tested
for 4-5 processes. We welcome customers or the third party inspection agencies to come to our factory for inspection.


Q3: Do you provide samples ? Is it free or extra ?
A: Yes, we could offer the sample for free charge but freight cost shall be paid by your Party.
