Product Details:
|
| Name: | Galvanized Steel Bar | Grade: | ASTM A106, ASTM A53, API 5L Gr.B, DIN17175, DIN1629 |
|---|---|---|---|
| Standard: | JIS, AiSi, ASTM, GB, DIN, EN | Length: | 1-12m |
| Diameter: | 8mm-610mm | Tolerance: | ±0.01% |
| Highlight: | Wear Resistant Galvanized Steel Bar,Galvanized Steel Bar S235,galvanized steel round bar SS400 |
||
High-Strength Wear-Resistant Round Steel/Bar S235 S355 1045 S35C S45C A36 SS400 Alloy Mild Carbon
Description
Galvanization is a common method used to protect steel in corrosive conditions and galvanized reinforcing bars have been available for many years. The ASTM specification for galvanized reinforcing bars is ASTM A767/ A767M, Standard Specification for Zinc-Coated (Galvanized) Steel Bars for Concrete Reinforcement. Galvanized reinforcing bar may be ordered either as straight bars that are galvanized prior to fabrication or as bars that are galvanized after the bars have been fabricated. The A767/A767M specification provides for two coating weights, a Class 1 (3.50 oz/ft2) or Class 2 (2.00 oz/ft2). However, there are no guidelines concerning the use of Class 1 or Class 2, although most transportation agencies specify Class 1.
|
Product name:
|
Carbon Steel Bar/Rod
|
|
Standard
|
JIS, AiSi, ASTM, GB, DIN, EN
|
|
Grade
|
ASTM A106, ASTM A53, API 5L Gr.B, DIN17175, DIN1629
|
|
Brand Name
|
DeNuo
|
|
Diameter
|
8mm-610mm
|
|
Length
|
1-12m
|
|
Model Number
|
NVA, NVD, A32, A36, AH32, AH36,B, 16MnL, D32, D36, DH32, DH36, EH32, 36, Q195, Q235, Q235B, Q345, 1050#, 16Mn, 20Mn, 35Mn, 45Mn, 50Mn, 20Mn2, 35Mn2, 45Mn2.
15CrMo, 35CrMo, 42CrMo, 20CrMo, 12Cr1MoV, 27SiMn, 60Si2Mn, 20Cr, 40Cr15GrMoG, 10GrMo910, 12Gr2MoG, 12Gr1MoVG, 1Gr5Mo, 1Gr9Mo , P11, T11, T91, T22, P22, P5, P9, WB36 |
|
Shape
|
Round
|
|
Certification
|
ISO, BV, SGS, MTC
|
|
Tolerance
|
±0.01%
|
|
Surface Treatment
|
Black Painted, PE Coated, Galvanized or Customized All Available
|
|
Place of Origin:
|
China
|
|
Application:
|
Industries
|
|
Tolerance:
|
±0.01%
|
|
Technique:
|
Hot Rolled
|
| Grade | Chemical Composition | Mechanical Properties | ||||||
| C | Mn | Si | S | P | Yield | Tensile | Elongati | |
| Strength Mpa | Strenth Mpa | -on % | ||||||
| Q195 | 0.06-0.12 | 0.25-0.50 | ≤0.30 | ≤0.045 | ≤0.05 | ≥195 | 315-430 | ≥33 |
| Q215 | 0.09-0.15 | 0.25-0.55 | ≤0.30 | ≤0.05 | ≤0.045 | ≥215 | 335-450 | ≥27 |
| Q235 | 0.12-0.20 | 0.30-0.67 | ≤0.30 | ≤0.045 | ≤0.04 | ≥235 | 375-500 | ≥26 |
| Q345 | ≤0.20 | 1.00-1.60 | ≤0.55 | ≤0.04 | ≤0.04 | ≥345 | 470-630 | ≥22 |
