Product Details:
|
| Product Name: | Galvanized Flat Steel Plate 40*6 60*8 ISO9001 For Building Structure | Length: | 5-15mm |
|---|---|---|---|
| Standard: | AISI,ASTM,DIN,JIS,GB | Width: | 150-625mm |
| Certificate: | BIS, JIS, ISO9001, ASTM, DIN, GB | Thickness: | 8-50mm |
| Highlight: | 60X8 Galvanized Flat Steel,40X6 Galvanized Flat Steel,steel flat sheet galvanised Building Structure |
||
Galvanized Flat Steel 4-60mm Aisi Z40-Z275 100-200mm Width
Product Description:
1. The product specifications are special, the thickness is 8-50mm, the width is 150-625mm, the length is 5-15m, and the product specifications are relatively dense, which can meet the needs of users. It can be used instead of the middle plate and can be directly welded without cutting.
2. The product surface is smooth and clean
3. Both sides are vertical and the water chestnut is clear
4. The scale of the product is accurate, the difference of three points, and the difference of the same grade is better than the standard of steel plate
5. The product material adopts the national standard, which is the same as the steel plate
|
Thickness
|
8-50mm
|
|
Width
|
150-625mm
|
|
Length
|
2m, 5.8m, 6m, 12m,or as required.
|
|
Surface
|
Black, peeled, polishing, bright, sand blast, hair line, etc.
|
|
PACKAGE
|
Standard export package,bundled wooden box,suit for all kinds of transport
|
|
APPLICATION
|
Stainless steel flat bar are widely used in petroleum,chemical and medical
industry,machinery,instrument and machinery structure parts,etc. |
| Chemical Composition | ||||||
| GRADE | C | Si | Mn | P | S | Ti |
| SGCC/DX51D+Z | ≤0.10 | ≤0.50 | ≤0.60 | ≤0.10 | ≤0.030 | ≤0.020 |
| DX52D+Z | ≤0.10 | ≤0.50 | ≤0.60 | ≤0.10 | ≤0.030 | ≤0.020 |
| SGCD/DX53D+Z | ≤0.10 | ≤0.30 | ≤0.50 | ≤0.05 | ≤0.030 | ≤0.020 |
| SGCE/DX54D+Z | ≤0.10 | ≤0.30 | ≤0.30 | ≤0.03 | ≤0.020 | ≤0.020 |
| DX56D+Z | ≤0.10 | ≤0.30 | ≤0.30 | ≤0.03 | ≤0.020 | ≤0.020 |
| Structural | ≤0.20 | ≤0.60 | ≤1.70 | ≤0.10 | ≤0.045 | |
| Grade | Chemical Composition | Mechanical Properties | ||||||
| C | Mn | Si | S | P | Yield | Tensile | Elongati | |
| Strength Mpa | Strenth Mpa | -on % | ||||||
| Q195 | 0.06-0.12 | 0.25-0.50 | ≤0.30 | ≤0.045 | ≤0.05 | ≥195 | 315-430 | ≥33 |
| Q215 | 0.09-0.15 | 0.25-0.55 | ≤0.30 | ≤0.05 | ≤0.045 | ≥215 | 335-450 | ≥27 |
| Q235 | 0.12-0.20 | 0.30-0.67 | ≤0.30 | ≤0.045 | ≤0.04 | ≥235 | 375-500 | ≥26 |
| Q345 | ≤0.20 | 1.00-1.60 | ≤0.55 | ≤0.04 | ≤0.04 | ≥345 | 470-630 | ≥22 |
Product Details:
Advantage:
Application:
Packing and delivering:
FAQ:
1.Q : Do you provide samples? Is it free or extra?
A : Yes, we can provide samples for free, but the shipping and necessary taxes will be paid by you.
2.Q : How is your quality? How do you guarantee the quality?
A : Our company has passed many certifications, and each product has to go through 4-5 process inspections, and there are corresponding
Quality inspection reports and certificates. Welcome customers to visit our factory.
3.Q: Can we visit your factory?
A: A warm welcome. Once we have your schedule, we will arrange a professional sales team to follow up your case.
5.Q:What is the terms of packing?
A: Generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers’ requirement.
