ASTM A588 Hot Rolled Steel Galvanized U Channel Cold Formed Section 80 - 200mm

ASTM A588 Hot Rolled Steel Galvanized U Channel Cold Formed Section 80 - 200mm
ASTM A588 Hot Rolled Steel Galvanized U Channel Cold Formed Section 80 - 200mm ASTM A588 Hot Rolled Steel Galvanized U Channel Cold Formed Section 80 - 200mm

Large Image :  ASTM A588 Hot Rolled Steel Galvanized U Channel Cold Formed Section 80 - 200mm

Product Details:
Place of Origin: Jiangsu,China
Brand Name: TISCO
Certification: ISO9001 14001 BV TUV PED DNV etc
Model Number: Q235B Q345B
Payment & Shipping Terms:
Minimum Order Quantity: 1 MT
Price: Negotiable
Packaging Details: Exporting package/wooden box package/Or per customers' requirements
Delivery Time: 7-15 work days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 8000MT/Month

ASTM A588 Hot Rolled Steel Galvanized U Channel Cold Formed Section 80 - 200mm

Description
Standard: AISI, ASTM, DIN, GB, JIS, SUS Application: Construction Supporting System
Grade: A36 Tolerance: ±1%
Flange Width: L/C T/T (30%DEPOSIT) Web Thickness: 45 - 75 Mm (UPN) & 40 - 76 Mm (UPE)
Flange Thickness: 8 - 11.5 Mm (UPN) & 7.4 - 9.0 Mm (UPE) Delivery Time: 15-21 Days
Highlight:

ASTM A588 Galvanized U Channel

,

U Shaped Steel Channel 200mm

,

Cold Formed Section Galvanized U Channel

ASTM A588 Hot Rolled U Shape Steel Channel Galvanized Cold Formed Section 80 - 200 Mm 3 M 6 M



Descriptions:



Steel channels are extensively used in a lot of applications. There are mainly three types of surface treatments to code with the conditions. Black or non-treatment is not frequently used for the steel will rust easily without any protective layers. Hot-dip galvanization and primer is the common treatments. Zinc coating resists environmental and weather corrosion, while primer does better. You can choose any kind according to your own application.



Product Name
carbon Steel Channel
Technology
hot rolled
Surface treatmen
black, galvanized or primed
Sizes
IPN & IPE European Standard
Web width
42 - 215 mm
Depth
80 - 600 mm
Web thickness
3.8 - 21.6 mm
Note
Special steel beam sizes are customized on order



Steel grade
Styles
Carbon, max, %
Manganese, %
Phosphorus, max, %
Sulfur, max, %
Silicon, %
A36
Steel shapes
0.26
--
0.04
0.05
≤0.40
A529 grade 50
Steel channel
0.27
1.35
0.04
0.05
≤0.40
A572 steel
42
0.21
1.35
0.40
0.04
0.05
50
0.23
1.35
0.40
0.04
0.05
55
0.25
1.35
0.40
0.04
0.05
A588 grade A
Steel channels
0.19
0.80 - 1.25
0.04
0.05
0.30 - 0.65



Product details



Item
Depth (mm)
Flange width (mm)
Web thickness (mm)
Flange thickness (mm)
weight (kg/m)
UPN80
80
45
6
8
8.64
UPN100
100
50
6
8.5
10.6
UPN120
120
55
7
9
13.4
UPN140
140
60
7
10
16
UPN160
160
65
7.5
10.5
18.8
UPN180
180
70
8
11
22
UPN200
200
75
8.5
11.5
25.3



ASTM A588 Hot Rolled Steel Galvanized U Channel Cold Formed Section 80 - 200mm 0



Package



ASTM A588 Hot Rolled Steel Galvanized U Channel Cold Formed Section 80 - 200mm 1



Our Warehouse



ASTM A588 Hot Rolled Steel Galvanized U Channel Cold Formed Section 80 - 200mm 2



Certificates



ASTM A588 Hot Rolled Steel Galvanized U Channel Cold Formed Section 80 - 200mm 3



Production Line



ASTM A588 Hot Rolled Steel Galvanized U Channel Cold Formed Section 80 - 200mm 4



FAQ:



1.Are You Manufacture or Trade Company?
We are manufacture,we have 12 years experience for supply Metal material and products in domestic.


2.Can you supply what is the service?
We can supply the kinds of metal materials and products,and we also can supply other process services.


3.Can you supply the free sample?
We can supply the free sample,but the sample express freight should be by you.


4.What about your the fast lead time if we place order?
It is normal 7-10 days after receive your deposit.


5.Which payment terms can you accept?
We can accept the TT,Western Union now or Negotiation.
