Product Details:
|
| Standard: | AiSi, ASTM, Bs, DIN, GB, JIS | Place Of Origin: | Jiangsu，China |
|---|---|---|---|
| Processing Service: | Cutting | Application: | Ship Plate, Boiler Plate, Container Plate, Making Pipes, |
| Technique: | Hot Rolled | Width: | 1000-2200mm |
| Type: | HR Steel Coil | Grade: | SS400,Q235,Q345R,SA302,SA516,A572,S275,S355 |
| Highlight: | Carbon Steel HR Cr Coils,Storage Systems HR Cr Coils,1.5mm HR Steel Coil |
||
— Hot Rolled Steel Sheet Hr Coil —
Description:
|
Hot rolled coils are strips made from billets that are heated in furnaces and then rolled by roughing and finishing units. It usually has very high strength, very high toughness, and easy processing and forming, and also has excellent weldability. Hot rolled coil specifications are very many varieties, and a very wide range of uses, from general engineering structures to the production of automotive parts, bridges, ships, boilers, pressure capacitors, etc. need a large number of hot rolled coil, in the hot rolled use before we will open the hot roll into a sheet or slit into thin strips for processing and the production of the final product. |
 |
| Product name | Carbon Steel Coil | ||
| Thickness | 1.5-25mm | ||
| Width | 1250-2500mm (Or as custom's request) ( regular width 1000mm, 1250mm, 1500mm ) | ||
| Coil ID | 508mm or 610mm | ||
| Coil weight | 3 - 8 ton or as client requirement | ||
| Standard | ASTM EN DIN GB ISO JIS BA ANSI | ||
| Steel Grade | Q235,Q345,ST37, Q195, Q215, A36,45# ,16Mn, SPHC | ||
| Technique | hot rolled cold rolled (as custom's request) | ||
| Surface treatment | Bare/Shot Blasted and Spray Paint or as required. | ||
| Application | Used in home appliances construction, machinery manufacturing, container manufacturing, shipbuilding, bridges, etc. | ||
| Package | Standard export package (Plastic film in the first layer,second layer is Kraft paper. Third layer is galvanized sheet) | ||
| Payment Terms | T/T or L/C | ||
| Delivery time | Within 15 workdays after deposit received | ||
| Remarks | Insurance per to Contract terms; MTC will be handed on with shipping documents; We accept the third party certificatation test. |
||
| Standard | Grade | General Size | Delivery Condition |
| ASTM A36 | A36/A36-B | 5-20 * 2300-2500 * C | Boron added or Black Condition |
| ASTM A283 | A283-B/A283C | 5-20 * 2300-2500 * C | Boron added or Black Condition |
| ASTM A572 | A572Gr50-B/A572Gr42-B | 5-20 * 2300-2500 * C | Boron added or Black Condition |
| ASTM A515 | A515Gr70 | 5-20 * 2300-2500 * C | Boron added or Black Condition |
| ASTM A516 | A516Gr70 | 5-20 * 2300-2500 * C | Boron added or Black Condition |
| JIS G 3101 | SS400-B | 5-20 * 2300-2500 * C | Boron added or Black Condition |
| JIS G3136 | SN400B | 5-20 * 2300-2500 * C | Boron added or Black Condition |
| EN10025-2:2004 | S235JR-S355K2+N | 5-20 * 2300-2500 * C | Boron added or Black Condition |
| EN10025-5:2004 | S355J2W/S355K2W | 5-20 * 2300-2500 * C | Boron added or Black Condition |
| Grade | Rank | Chemical Composition( %) | ||||
| C | Mn | Si | S | P | ||
| Q195 | 0.06~0.12 | 0.25~0.50 | ≤0.3 | ≤0.05 | ≤0.045 | |
| Q215 | A | 0.09~0.15 | 0.25~0.55 | ≤0.3 | ≤0.05 | ≤0.045 |
| B | ≤0.045 | |||||
| Q235 | A | 0.14~0.22 | 0.30~0.65 | ≤0.3 | ≤0.05 | ≤0.045 |
| B | 0.12~0.20 | 0.30~0.70 | ≤0.045 | |||
| C | ≤0.18 | 0.35~0.80 | - | ≤0.04 | ≤0.04 | |
| D | ≤0.17 | ≤0.035 | ≤0.035 | |||
| Q255 | A | 0.18~0.28 | 0.40~0.70 | ≤0.3 | ≤0.05 | ≤0.045 |
| B | ≤0.045 | |||||
| Q275 | 0.28~0.38 | 0.50~0.80 | ≤0.35 | ≤0.05 | ≤0.045 | |
