Product Details:
|
| Technique: | Hot Rolled And Cold Rolled | Thickness: | 2 - 200 Mm |
|---|---|---|---|
| Length: | 12M, 6m, 3-12m | Grade: | 300 Series, 310S, 316Ti, 316L, 316, 304, 304L |
| Application: | Industry | Standard: | AISI,ASTM,DIN,JIS,BS,NB |
| Highlight: | 12m Stainless Steel Pipe,Industry Stainless Steel Seamless Pipe,Annealed Stainless Steel Pipe |
||
— 201,202 Stainless Steel Pipe —
Description
· Material: 201,302,303,304,304l,316,316l,321,309s,310s,904l etc
· Size(round pipe): 9.5-219 mm or customized
· Size (square pipe): 10×10-150×100 mm or customized
· Size (oval pipe): 30×15,80×40 mm or customized
· Thickness: 0.24-3 mm
· Length: 6m or according to customer’s request
· Outer diameter: 8-219mm
· Tolerance: Outer diameter :±0.2mm Thickness :±0.02mm Length :±0.5mm
· Process method: Code drawn, annealed with nitrogen protection, ultrasonic,automatic shape, polished
· Finishing: A: sanded B: 400#-600# mirror C: hairline brushed D: TIN titanlum
· E : HL brushed & mirror (two kinds of finishing for one pipe)
|
Model
|
Stainless steel tubes/pipes
|
|||
|
Standard
|
ASTM A213, ASTM A312, ASTM A789, ASTM A790 Stainless steel tubes/pipes
|
|||
|
Material Grade
|
201/202/304/316/S31803/S32750 Stainless steel tubes/pipes ss pipe 304
|
|||
|
Outer Diameter
|
0.1mm-219.1mm ss pipe 304 ss pipe 304 ss pipe 304 ss pipe 304 ss pipe 304
|
|||
|
Thickness
|
0.05mm-20mm ss pipe 304 ss pipe 304 ss pipe 304 ss pipe 304 ss pipe 304
|
|||
|
Length
|
≤12000mm or as per customer request China supplier China supplier China supplier
|
|||
|
Tolerance
|
a) Outer Diameter: +/-0.2mm stainless steel pipes/tubes ss pipe 304 ss pipe 304
|
|||
|
b) Thickness: +/- 10% OR as customer request ss pipe 304 ss pipe 304 ss pipe 304
|
||||
|
c) Length: +/- 10mm stainless steel pipes/tubes ss pipe 304 ss pipe 304 ss pipe 304
|
||||
|
Surface
|
Satin / Hairline: 180#, 320# stainless steel pipes/tubes ss pipe 304 ss pipe 304
|
|||
|
Polish: 400#, 600#, 800# or Mirro surface stainless steel pipes/tubes price
|
||||
|
Picking stainless steel pipes/tubes price China supplier astm 201 316 ss pipe 304
|
||||
|
Application
|
Decoration (Processed into raillings, handrails, doors and Windows), ss pipe 304
|
|||
|
medical, industry, etc stainless steel pipes/tubes price stainless steel pipes/tubes
|
||||
|
packing
|
Plastic bag/woven packing stainless steel pipes/tubes price ss pipe 304
|
|||
|
(please send details packing to us if you have other requirements) ss pipe 304
|
||||
Available grade for decoration stainless steel pipe
| GRADE | GB/T 1220-2007 | CB 1220-92 | ASTM | UNS | DIN | JIS | KS |
| Austenitic | 12Cr17Mo6Ni5N | 1Cr17Mo6Ni5N | 201 | S20100 | 1.4372 | SUS201 | STS201 |
| 12Cr18Mn8Ni5N | 1Cr18Mn8Ni5N | 202 | S20200 | 1.4373 | SUS202 | STS202 | |
| 06Cr19Ni10 | 0Cr18Ni9 | 304 | S30400 | 1.4301 | SUS304 | STS304 | |
| 022Cr19Ni10 | 00Cr19Ni10 | 304L | S30403 | 1.4306 | SUS304L | STS304L | |
| 10Cr18Ni12 | 1Cr18Ni12 | 305 | S30500 | 1.4303 | SUS305 | STS305 | |
| 06Cr23Ni13 | 0Cr23Ni13 | 309S | S30908 | 1.4833 | SUS309S | STS309S | |
| 06Cr25Ni20 | 0Cr25Ni20 | 310S | S31008 | 1.4845 | SUS310S | STS310S | |
| 06Cr17Ni12Mo3Ti | 0Cr18Ni12Mo3Ti | 316Ti | S31635 | 1.4571 | SUS316Ti | STS316Ti | |
| 022Cr17Ni12Mo | 00Cr17Ni12Mo2 | 316L | S31603 | 1.4404 | SUS316L | STS316L | |
| 02Cr19Ni13Mo3 | 00Cr19Ni13Mo3 | 317L | S31703 | 1.4438 | SUS317L | STS317L | |
| 06Cr19Ni11Ti | 0Cr18Ni10Ti | 321 | S32100 | 1.4541 | SUS321 | STS321 | |
| 06Cr18Ni11Nb | 0Cr18Ni11Nb | 347 | S34700 | 1.4550 | SUS347 | STS347 | |
| 015Cr21Ni26No5Cu2 | - | 904L | N08901 | 1.4539 | - | - | |
| Available Type | Round Pipe/ Square Pipe / Rectangular Pipe / Hexagonal Tube / Pipe Coil Etc | ||||||
Chemical composition and physical property
| Grade |
C (Max) |
Mn (Max) |
P (Max) |
S (Max) |
Si (Max) |
Cr | Ni | Mo | Nitrgeo(Max) | Cu/Other |
| 201 | 0.15 | 5.5-7.5 | 0.06 | 0.03 | 1.0 | 16.0-18.0 | 0.5-1.0 | -- | 0.25 | -- |
| 202 | 0.15 | 7.5-10.0 | 0.06 | 0.03 | 1.0 | 17.0-19.0 | 1.5-2.5 | -- | 0.25 | -- |
| 304 | 0.08 | 2.0 | 0.045 | 0.03 | 1.0 | 18.0-20.0 | 8.0-10.0 | -- | 1.0 | |
| 304L | 0.03 | 2.0 | 0.045 | 0.03 | 1.0 | 18.0-20.0 | 8.01-10.5 | -- | 0.1 | -- |
| 309S | 0.08 | 2.0 | 0.045 | 0.03 | 1.0 | 22.0-24.0 | 12.0-15.0 | -- | -- | -- |
| 310S | 0.08 | 2.0 | 0.045 | 0.03 | 1.5 | 24.0-26.0 | 19.0-22.0 | -- | -- | -- |
| 316L | 0.03 | 2.0 | 0.045 | 0.03 | 1.0 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | 0.1 | |
| 321 | 0.08 | 2.0 | 0.045 | 0.03 | 0.75 | 17.0-19.0 | 9.0-12.0 | -- | 0.1 | -- |
| 2205 | 0.025 | 1.27 | 0.026 | 0.0015 | 0.58 | ≤22.50 | ≤5.20 | ≤3.10 | -- | -- |
| 904L | 0.02 | 2.0 | 0.045 | 0.035 | 1.0 | 19.0-23.0 | 23.0-28.0 | 4.0-5.0 | -- | -- |
| Grade | TS(Mpa) | YS(Mpa) | EL(%) | RRA(%) | Density |
| 201 | ≥520 | ≥275 | 55-60 | - | 7.93 |
| 202 | ≥590 | ≥245 | - | - | 7.93 |
| 304 | ≥520 | ≥205 | ≥40 | ≥60 | 7.93 |
| 304L | ≥520 | ≥205 | ≥40 | ≥60 | 7.93 |
| 309S | ≥515 | ≥205 | ≥40 | ≥50 | 7.98 |
| 310S | ≥520 | ≥205 | ≥40 | ≥50 | 7.98 |
| 321 | ≥520 | ≥205 | ≥40 | ≥50 | 7.98 |
| 316L | ≥485 | ≥170 | ≥30 | ≥40 | 7.98 |
