Product Details:
|
| Name: | Stainless Steel Sheet | Thickness: | 0.2mm-100mm |
|---|---|---|---|
| Width: | 20-160mm. Customizable, 100mm-2000mm | Tolerance: | ±1% |
| Grade: | 300 Series,Customizable, 600 Series,200 Series,300 Series, 400 Series | Surface Treatment: | BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D |
| MOQ: | As Your Requirement | Processing Service: | Welding, Punching, Cutting, Bending, Decoiling |
| Highlight: | Astm Inox Sus Stainless Steel Plates,4Mm 304 Stainless Steel Plates,100mm Stainless Steel Plates |
||
— Stainless Steel Sheet —
Product Specification
Stainless plate products are used in industries that include but are not limited to food processing, chemical processing, power generation, high vacuum, waste water treatment, heat treatment, pulp and paper, pharmaceutical and brewing.
Stainless steel, any one of a family of alloy steels usually containing 10 to 30 percent chromium. In conjunction with low carbon content, chromium imparts remarkable resistance to corrosion and heat. Other elements, such as nickel, molybdenum, titanium, aluminum, niobium, copper, nitrogen, sulfur, phosphorus, or selenium, may be added to increase corrosion resistance to specific environments, enhance oxidation resistance, and impart special characteristics.
|
Product Name
|
Stainless Steel Plate
|
|
Material Type
|
Ferrite stainless steel, magnetic; Austenitic stainless steel, Non-magnetic.
|
|
Grade
|
Mainly201, 202, 304, 304L, 304H, 316, 316L,316Ti,2205, 330, 630, 660, 409L, 321, 310S, 410, 416, 410S, 430, 347H, 2Cr13, 3Cr13 etc
|
|
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,
321,347
|
|
|
200series:201,202,202cu,204
|
|
|
400series:409,409L,410,420,430,431,439,440,441,444
|
|
|
Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc
|
|
|
Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304
|
|
|
Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
|
|
|
Technology
|
Cold Rolled /Hot Rolled
|
|
Length
|
2000/2438/2500/3000/3048 mm
|
|
Width
|
1000/1219/1250/1500 mm
|
|
Thickness
|
0.4-3mm(cold Rolled), 3-200mm(hot Rolled)
|
|
|
BA, 2B, 2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed,perforated,water ripple
|
|
Leveling: improve flatness, esp. for items with high flatness request.
|
|
|
Skin-Pass: improve flatness, higher brightness
|
|
|
Other Choices
|
Cutting:Laser cutting, help the customer to cut the required size
|
|
Protection
|
1. Inter paper available
|
|
2. PVC protecting film available
|
|
|
Price Item
|
FOB,CIF,DDU,FCA,EXW ,.etc
|
|
Advantage
|
We have stock, about 20000 tons.
|
|
Inspection
|
1.Provide MTC (Mill Test).
2.Accept the inspection by the third party agent
|
| Grade | C(%) | Si(%) | Mn(%) | P(%) | S(%) | Cr(%) | Ni(%) | N(%) | Cu(%) |
| 304 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 18.00-20.00 | 8.00-10.50 | ≤0.10 | / |
| 304L | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 18.00-20.00 | 8.00-10.50 | ≤0.10 | / |
| 304H | 0.04-1.00 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 18.00-20.00 | 8.00-10.50 | ≤0.10 | / |
| Grade |
Tensile Strength (Mpa) |
Yield Strength (Mpa) |
Elongation (%) |
Rate Of Reduction In Area (%) |
Density (G/Cm3) |
Hardness (HB) (HRB) (HV) |
| 304 | ≥515 | ≥205 | ≥40 | / | 7.93 |
≤201HBW;≤92HRB; ≤210HV |
| 34L | ≥515 | ≥205 | ≥40 | / | 7.93 | ≤187HB; ≤90HRB; ≤200HV |
| 304H | ≥515 | ≥205 | ≥40 | / | 7.93 | / |
Product Details
Surface
|
Surface Finished
|
Characteristics
|
application
|
||
|
NO.1
|
Finished by hot-rolling, smoother and pickling, characterized by white pickled surface.
|
Chemical industry equipment, Industrial tanks.
|
||
|
2B
|
Finished by anneal treatment, pickling after cold rolling, followed by skin pass line to more brighter and smoother surface.
|
General application medical instruments, Tableware.
|
||
|
BA
|
Bright anneal treatment after cold rolling.
|
Kichen utenstil, Kitchen ware,Architectural purpose.
|
||
|
NO.4(Satin)
|
Finished by incontinuous linear brushing
|
Architecture,industries,Escalators, Kitchen ware, Vehicles.
|
||
|
Hairline
|
Finished by continuous linear brushing
|
Architecture,industries,Escalators, Kitchen ware, Vehicles.
|
||
|
8K(mirror)
|
A mirror-like reflective surface by polishing with finer abrasives over 800 mesh.
|
Refletor, Mirror, Interior- Exterior decoration for building.
|
||
