Product Details:
|
Name: | Galvanized Steel Hollow Section Square Rectangular Tube | Thickness: | 1.2-20mm |
---|---|---|---|
Out Diameter: | 10-1000mm | Tolerance: | Control With In The Standard, OD:+-1%, WT:+-10% |
Standard: | ASTM A106, ASTM A53, API 5L Gr.B, DIN17175,DIN1629 | Surface Treatment: | Galvanized,or Black |
Highlight: | Round Galvanized Steel Pipe tube,1.5Inch Galvanized Pipe tube,SS400 Galvanized Pipe tube |
1 Inch 1.5 Inch 2" 2.5 Inch 4 Inch Round Galvanized Steel Pipe SS400 Q195 Q235 Q345 6m & 5.8m Length
Detail:
The Galvanized Steel Pipe is made from high-quality SS400, Q195, Q235, and Q345 materials, ensuring durability and strength. It features a zinc-coated surface, providing excellent corrosion resistance. The pipe is available in various diameters, including 1/2 inch and 3/8 inch, and is coated with a zinc layer weighing 300g for enhanced protection. This Galvanized Steel Pipe is ideal for a wide range of applications due to its reliable construction and superior surface treatment.
Product name
|
galvanized Steel Hollow Section Square Rectangular Tube
|
|||
Material
|
S275J0H,S355JR,S355J0H,S355J2H,A36,SS400,Q195,Q235,Q345
|
|||
Surface treatment
|
Pre-galvanized, Hot dipped galvanized, Electro galvanized, Black, Painted, Threaded, Engraved, Socket.
|
|||
Shape
|
square or rectangular or round
|
|||
Thickness
|
1.2-20mm
|
|||
Length
|
3-12M according to client requirement
|
|||
OD(outer diameter)
|
square 10*10-1000*1000mm rectangular:10*15 800*1100mm Round:10.3mm-609mm
|
|||
|
Pre-galvanized :5μm-25μm
|
|||
Hot dip galvanized:35μm-200μm
|
||||
Technology
|
ERW,LSAW,SSAW,Seamless
|
|||
Packing
|
1.Big OD:in bulk 2.Small OD:packed by steel strips
3.woven cloth with 7 slats 4.according to the requirements of customers |
|||
MOQ
|
5 Tons
|
|||
Standards
|
BS1139-1775, EN1039, EN10219, JIS G3444:2004, GB/T3091-2001, BS1387-1985, DIN EN10025, ASTM A53 SCH40/80/STD, BS-EN10255-2004
|
Grade | Chemical Composition | Mechanical Properties | ||||||
C | Mn | Si | S | P | Yield | Tensile | Elongati | |
Strength Mpa | Strenth Mpa | -on % | ||||||
Q195 | 0.06-0.12 | 0.25-0.50 | ≤0.30 | ≤0.045 | ≤0.05 | ≥195 | 315-430 | ≥33 |
Q215 | 0.09-0.15 | 0.25-0.55 | ≤0.30 | ≤0.05 | ≤0.045 | ≥215 | 335-450 | ≥27 |
Q235 | 0.12-0.20 | 0.30-0.67 | ≤0.30 | ≤0.045 | ≤0.04 | ≥235 | 375-500 | ≥26 |
Q345 | ≤0.20 | 1.00-1.60 | ≤0.55 | ≤0.04 | ≤0.04 | ≥345 | 470-630 | ≥22 |
Packaging & Shipping:
Application:
certificate:
Related products:
FAQ:
1. Can I get free samples?
A: Yes, we can provide you the free samples, but you need to bear their own delivery costs.
2. Can I request to change the form of packaging and transportation?
A: Yes, We can change the form of the packaging and transportation according to your request, but you have to bear their own costs incurred during this period and the spreads.
3. Can I request to advance the shipment?
A: It should be depends on whether there is sufficient inventory in our warehouse.
