Product Details:
|
| Name: | 140g Zinc Galvanized Steel Coil 95HRB 1000mm Length Ma Steel DX51D | Zinc Coating: | 30-275g/m2 |
|---|---|---|---|
| Spangle Type: | Regular Spangle | Standard: | AiSi, ASTM, Bs, DIN, GB, JIS |
| Grade: | DX51D+Z/SGCC/DX51D/SPCC | Hardness: | 45HRB-95HRB |
| Highlight: | zinc Galvanized Steel Coil,140g Galvanized Steel Coil,steel galvanized coil DX51D |
||
140g Zinc Galvanized Steel Coil 95HRB 1000mm Length Ma Steel DX51D
Product Description:
Galvanized coil, steel sheet in melting zinc trough, the sticking of a layer of zinc sheet.
Mainly USES the continuous galvanizing process, namely the continuous roll of steel plate in the melt zinc plating tank made of galvanized steel sheet;Alloying of galvanized steel.
This kind of steel plate is made by hot dip method, but after the slot, immediately heated to a temperature of about 500 ℃, it make the generation of zinc and iron alloy membrane.
This kind of galvanized volumes with good coating of the sex and weldability.
Standard | JIS G 3302, ASTM A653,GB/T 2518-2008 |
Material | DX51D , SGCC , SGCH |
Hardness | 40HRB-90HRB |
Grade | G250-G550 |
Thickness | 0.15-0.8mm |
Width | 100-1250 mm |
popular width | 750mm, 762mm, 900mm, 914mm, 1000mm, 1200mm, 1220mm, 1250mm |
Zinc coating | 30g-275 g |
Paint type | PE/SMP/PVDF |
Spangle | zero / mini / regular / big spangle |
Paint band | Nippon / Beckers paint |
ID coil | 508/610 mm |
coil weight | 2T-8T per coil |
STEEL GRADE | CHEMICAL COMPOSITION % | MECHANIC PROPERTY | C.B OF COATING | ||||||
C | Si | Mn | S | p | T.S | Y.S | E.L | ||
x103 | x103 | x102 | x103 | x103 | Mpa | Mpa | % | d=180 | |
JIS G3302 SGCC | 12 | 30 | 41 | 31 | 21 | 480 | 300 | 13 | OK |
JIS G3302 SGCH | 12 | 10 | 21 | 18 | 6 | 680 | 650 | 20 | OK |
ASTM 653 CS.B | 29 | 30 | 60 | 35 | 30 | 386 | 250-380 | 20 | OK |
DX51D+Z | 20 | 21 | 18 | 1.8 | 11 | 355 | 245 | 38 | OK |
G550 | 12 | 6 | 73 | 5 | 17 | 715 | 654 | 8 | OK |
Product Details:
Application:
About us:
FAQ:
1) What is the delivery time?
Depends actual order, around 20 to 35 days.
2) What is the QC system?
We have QC staff of 5 persons and advanced equipment, each production is with MTC traced from Aluminum ingot lot. According to the standard we will inspect every producing step.
3) How many tons one 20 GP or 40 GP could load?
One 20 GP could load about 20 tons. And 40 GP load about 24 tons.
It depends on the different specification.
4) What market do you mainly sell to?
Australia, America,Asia,Middle East,Western Europe ,Africa etc.
5) What's your payment term?
