Product Details:
|
| Standard: | AiSi, ASTM, Bs, DIN, GB, JIS | Place Of Origin: | Jiangsu，China |
|---|---|---|---|
| Processing Service: | Cutting | Application: | ROOF |
| Technique: | Cold Rolled | Surface Treatment: | Galvanized |
| Width: | 762MM/914MM/1000MM | Type: | Galvanized Steel Coil |
| Highlight: | DX51D 0.12mm Galvanized Steel Coil,Galvanized Steel Coil 2000mm,AiSi Galvanized Steel Coil Sheet Strip |
||
— Galvanized Steel Coil —
|
Description
What is standard galvanized thickness?
What is the thickness of a galvanized coating? When it comes to the specification of hot dip galvanizing, most contractors know that to be standards compliant, 7mm steel requires an average coating thickness of '85 microns'.You can tell that metal is galvanized when it has a pattern to it that is known as a spangle pattern. A spangle pattern almost looks like someone dipped a sponge in gray paint and then sponge-painted the metal. You'll notice darker and lighter spots, much like you would see when a wall is sponge painted.
|
 |
| Standard | astm a526 a528 a444, a653, jis g3302, en10142 en1012, etc |
| Grade | DX51D+Z, DX52D+Z, DC52D+Z, DC51D+Z, S350GD+Z, G550, SGCC, DD52D+Z etc |
| Thickness | 0.12-3.0mm (customize, above 3.0mm available) |
| Width | 600-2000mm (customize) |
| Length | as customer requirements |
| Coil inner diameter | 508mm/610mm (customize) |
| Zinc coating | 20-600g/m2 |
| Raw material | cold rolled base. (hot rolled base also available) |
| Technique | hot dipped. (electro also available) |
| Coil weight | 3-8 tons |
| Tolerance | thickness +- 0.02 or +- 0.04, width +-5mm |
| Spangle type | zero spangle, small spangle, regular spangle, big spangle |
| Surface treatment | chromated/non-chromated, oiled/non-oiled, anti-fingerprints |
| Certification | CE, ISO9001-2008, SGS |
| Monthly output | 17000 tons |
| Packaging | 3 layers. kraft paper outside + water-proof plastic film in the middle + steel plate covered with strips outside |
| Landing port | qingdao/shanghai/tianjin port |
| Payment terms | T/T, L/C, western union paypal etc |
| Delivery time | it takes about 10 days for stock goods, or it will need 15-25 days if goods need to be customized |
| MOQ | as customer needs. reminder: more quantity reduce your purchase cost greatly |
| Inspection | third-party test |
| Cooperate brand | anshan steel, baotou steel, jiangsu shagang etc |
| Usage | Grade | Yield Strength (MPA) | Tensile Strength (MPA) | Elongation rate % |
| Punching galvanized steel | DX51D+Z | ~ | 270-500 | >=20 |
| DX52D+Z | 140-300 | 270-420 | >=22 | |
| DX53D+Z | 140-260 | 270-380 | >=26 | |
| DX54D+Z | 140-220 | 270-350 | >=30 | |
| Structure galvanized steel | S220GD+Z | >=220 | >=300 | >=18 |
| S250GD+Z | >=250 | >=330 | >=17 | |
| S280GD+Z | >=280 | >=360 | >=16 | |
| S320GD+Z | >=320 | >=390 | >=15 | |
| S350GD+Z | >=350 | >=420 | >=14 | |
| S400GD+Z | >=400 | >=470 | ~ | |
| S500GD+Z | >=500 | >=530 | ~ | |
| S550GD+Z | >=550 | >=560 | ~ |
