Product Details:
|
| Name: | SECC EG Dx51d Zinc Coated 24 26 28 Gauge Hot Dip Electro Galvanized Steel Sheet Cold Rolled Gi Metal Iron Plate | Technique: | Hot Rolled |
|---|---|---|---|
| Width: | 1m 2m | Tolerance: | 1% |
| Surface Treatment: | Electro Galvanized | Characteristics: | Good Ductility Safe And Environmental Friendly |
| Highlight: | SGCH Electro Steel Plate Sheet,Electro Galvanized Steel Sheet,DX51D+Z Electro Steel Sheet |
||
Fast Delivery SGCC SGCH DX51D+Z Electro Galvanized Steel Sheet Cold Rolled Gi Metal Iron Plate
Details
Electrogalvanized sheet is manufactured by electroplating a pure zinc coating on one or two sides of carbon steel sheet. This continuous electrolytic coating process can be used to apply the coating onto the surface of the steel sheet with an exceptionally uniform thickness. In addition, the coated sheet has a smooth, matte appearance similar to cold rolled sheet. Thus, the surface quality is exceptionally good for applications that require a high finish after painting, such as automotive exposed panels. The excellent control of the coating thickness that is achieved with the electrolytic deposition process is beneficial to enhance forming and joining operations, especially by contributing to more reliable results from automatic and robotic welding systems. Both the zinc and zinc-iron electrogalvanized coatings are readily paintable, but to achieve good resistance to corrosion, the coated-steel surface should be pretreated and primed prior to application of the finish paint coating.
|
Standard
|
ISO,JIS,AS EN,ASTM,etc
|
|
Grade |
Q195 Q235 Q345 Q235B Q345B,etc
|
|
SGCC SGCH SGC340 SGC400 SGC440 SGC490 SGC570,etc
|
|
|
SGHC SGH340 SGH400 SGH440 SGH490 SGH540,etc
|
|
|
DX51D DX52D DX53D DX54D DX55D DX56D DX57D,etc
|
|
|
S220GD S250GD S280GD S320GD S350GD S400GD S500GD S550GD,etc
|
|
|
SS230 SS250 SS275,etc
|
|
|
Modle number
|
0.12-4.0mm*600-1500mm
|
|
Width
|
600mm-1500mm or as your required
|
|
Thickness
|
0.12mm to 4mm or as your required
|
|
Length
|
Coil or as customer's request
|
|
Zinc coating
|
30g/m2 to 275g/m2
|
|
Tolerance
|
±1%
|
|
Hardness
|
Softy , half hard and hard quality or as your required
|
|
Coil Weight
|
3-8 Tons/coil
|
|
Coil ID
|
508mm / 610mm
|
|
Coating Material
|
PE,SMP,HDP,PVDF
|
|
Top Coating Thickness
|
15μm-25μm
|
|
Back Coated Thickness
|
5μm-20μm
|
|
Certification
|
ISO, CE,SGS,etc.
|
|
MOQ
|
3 tons,can be customized according to your requirements.
|
|
Delivery Time
|
Usually within 7 days, the time depends on the number of products.
|
|
Payment
|
T/T, D/A, D/P, L/C, Western Union, MoneyGram or according to customer requirements.
|
|
Packing details
|
Waterproof paper+plastic film+iron packing+bunding
or as per customers request.
|
Production line
Packaging & Shipping
Applications
Certificates
